HOME / LAW AND GARDEN / Brushcutter and Trimmer / Cordless Brushcutter /

Spare parts: Cordless lawn mower MAKITA DUR192LZ (Body only)

Brand : MAKITA

MAKITA

MAKITA Genuine Parts
Need a new one?
Cordless lawn mower MAKITA DUR192LZ  (Body only) Cordless lawn mower MAKITA DUR192LZ (Body only)
4,770 THB
✓ In stock
Details
Full image
Parts diagram Cordless lawn mower MAKITA DUR192LZ  (Body only)
Click a number to find the part · scroll on the diagram to zoom, drag to panTap a number to find the part · tap + to zoom, drag to pan No price yetNot listed Brand: MAKITA · View this machine
Parts 48 items
1
Motor housing set
183R54-1 · same part as # 14
280 THB
3
Stator
629A22-3
390 THB
4
Rotor assembly
519643-2
600 THB
5
Ball bearing 625ZZ
210235-7 · same part as # 10
40 THB
6
80 THB
7
O-ring 21
213843-3
Also fits: DUX18Z DUX18ZX1
20 THB
8
Helical gear 11
227831-4
No price yet
Ask for price
10
Ball bearing 625ZZ
210235-7 · same part as # 5
40 THB
11
Helical gear 32
227830-6
100 THB
12
Cutter shaft
327678-7
100 THB
13
Ball bearing 6001DDW
210216-1
Also fits: DUC307ZX1 UV001G
90 THB
14
Motor housing set
183R54-1 · same part as # 1
280 THB
15
170 THB
18
Joint 24
347747-8
220 THB
19
20 THB
21
30 THB
22
Protector clamp
347667-6
Also fits: DUR190UZX1
60 THB
23
70 THB
24
Cutter
346855-2
Also fits: DUR190UZX1 DUR368AZ
120 THB
25
Protector N 330
412580-8
200 THB
27
Pipe complete C
140W46-3
340 THB
28
Pipe complete B
140W45-5
310 THB
29
Loop handle 24
457937-6
280 THB
31
Pipe clamp 29
347011-7
70 THB
32
490 THB
34
60 THB
36
Grip housing set
183R55-9 · same part as # 44
340 THB
37
360 THB
38
Switch C3JW-1A-PA-2
651494-8
Also fits: DUX18Z DUX18ZX1
490 THB
40
Lock off lever
412863-6
Also fits: DUX18Z DUX18ZX1
40 THB
41
40 THB
44
Grip housing set
183R55-9 · same part as # 36
340 THB
45
20 THB
46
Controller
620D78-7
2,400 THB
47
20 THB
71
O-ring 21
213925-1
Also fits: DUX18Z DUX18ZX1 UG001GZ
30 THB
81
Helical gear 11
227883-5
130 THB
291
Loop handle 24
413L67-5
1,080 THB
Specifications
Cutting width of trimmer head 300 MM(11-3/4")
Cutting width 230 MM(9")
No-load speed (RPM) 4,500-6,000 RPM
Length 1,834 MM
Orbit diameter M10x1.25LH
Weight with standard battery 2.7 - 3.0 kg.
Batteries 18V
